Product Model | AT1~6UXL22, AT1~6UXL24, AT1~6UXL28 | |
Optic Power Range | Dioptric Power Range and Increment | +5.0 D to +36.0 D, in 0.5 D increment |
Cylindrical Power Range | 1.00 D, 1.50 D, 2.25 D, 3.00 D, 4.00 D, 4.50 D | |
Optical Design | Anterior surface with toric design and posterior surface with high-order coefficient aspheric design | |
Body Diameter | 6.0 mm | |
Overall Diameter | 13.0 mm | |
Haptic Design and Angulation | Modified L-haptic, 1.5° angulation | |
Optic edge | 360-degree square edge (a squared posterior optic edge that provides a 360-degree barrier) | |
IOL Material | Hydrophobic acrylic | |
Filtration | UV blocking | |
Optimized Constants | Ultrasound Biometry | A=118.9 |
Optical Biometry | A=119.2 | |
SRK/T | A=119.2 | |
SRK/Ⅱ | A=119.6 | |
Haigis | a0=1.50, a1=0.40, a2=0.10 | |
Hoffer Q | pACD=5.69 | |
Holladay І | Sf=1.95 | |
Holladay Ⅱ | ACD=5.69 | |
Barrett | LF=2.0, DF=2.5 | |
